B25690A1427K303
| Parameters | |
|---|---|
| Series | MKP DC Link - Resin Top |
| Part Status | Active |
| Termination | Threaded, Female |
| Package / Case | Radial, Can |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 85°C |
| Size / Dimension | 4.567" Dia (116.00mm) |
| Ratings | - |
| Capacitance | 420 µF |
| Tolerance | ±10% |
| Dielectric Material | - |
| Applications | General Purpose |
| ESR (Equivalent Series Resistance) | 1.7 mOhms |
| Lead Spacing | - |
| Features | - |
| RoHS | RoHS |
| Height - Seated (Max) | 5.000" (127.00mm) |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 1300V (1.3kV) |
B25690A1427K303 CAP FILM 420UF 1.3KVDC SCREW
The B25690A1427K303 is a high-efficiency wide-input synchronous step-down battery charge management IC developed by Texas Instruments, belonging to the industry-recognized BQ25690 power management product family, which integrates advanced power path management, overvoltage protection, battery temperature monitoring and adaptive current regulation functions into a compact high-density package to minimize external component count for space-constrained portable system designs. This device supports a maximum DC input voltage of 1300V and a rated capacitance of 420uF, with a high-efficiency conversion topology that maintains stable charging performance across a wide operating temperature range from -40°C to +125°C, making it perfectly suited for high-power energy storage systems, industrial power supplies, new energy vehicle auxiliary circuits and high-voltage industrial filtering scenarios.
